MATRIX Control Panel OP71 Operating MATRIX control panel OP71
PR-2009-0021-GB • Subject to modifications • R5-04/2016 71
Fans ➜ Factor
The "Factor" submenu indicates the speed relationship between master and slave fan
using a multiplicative factor. This submenu is available only if the slave control using
factor was selected in the submenu "Control Mode".
The slave fan speed is calculated as follows:
Speed of the slave fan = speed of the master fan * factor
If the factor = 1 then both fans are operated at the same speed
Offset Supply-air fan follows extract air fan with
speed offset
Speed.OP Assignment of fan speed using control panel
Factor Supply-air fan follows extract air fan with fac-
tor
Speed.OP Assignment of fan speed using control panel
Speed ext. Fan speed setting with external 0-10V input -------- Without extract-air fan
Speed ext. Fan speed setting with external 0-10V input Offset Extract-air fan follows supply-air fan with
speed offset
Speed ext. Fan speed setting with external 0-10V input Factor Extract-air fan follows supply-air fan with fac-
tor
-------- Without supply-air fan Speed ext. Fan speed setting with external 0-10V input
Offset Supply-air fan follows extract air fan with
speed offset
Speed ext. Fan speed setting with external 0-10V input
Factor Supply-air fan follows extract air fan with fac-
tor
Speed ext. Fan speed setting with external 0-10V input
Supply-air fan Extract-air fan
Factor
1.20
Value range: 0 to 2
Adjustable steps: 0.01
Factory setting: 1
