Chapter 4 Troubleshooting
Milling Quality Problems
The Milled Surface Is Not Attractive
Is the workpiece rmly secured in
place?
Check the mounting condition of the workpiece. If the
workpiece is not mounted on the machine correctly,
the workpiece may come loose during milling and may
become misaligned.
P.24
Is the milling bur worn?
If the same milling bur is used for milling for a long peri-
od of time, it will become worn and aect milling results.
Try replacing the milling bur with a new one. The work
time of the milling bur can also be managed in VPanel.
P.15
Are the milling conditions too
strict?
Strict milling conditions may aect milling results.
Review the CAM milling conditions.
—
Is the adapter properly attached?
Review the mounting condition of the adapter.
If the adapter is not properly attached, it may come
loose during milling and may become misaligned.
P.33
There Is a Line of Level Difference in the Milling Results
Is the machine out of correction?
The origin point may become out of position due to
prolonged use or relocating the machine, which can
result in a line of level dierence. Perform automatic
correction. If the expected results cannot be obtained
even after performing automatic correction, perform
manual correction. With manual correction, changing
the Y value in Origin point may improve the situation.
P.53
Are the CAM milling conditions
correct?
Depending on the milling conditions, a line of level dif-
ference may occur. Review the CAM milling conditions.
—
Chipping Occurs (Edges of Milling Products Become Chipped)
Is the installation base of the
machine secure?
The vibration from milling can shake the installation
base. Install the machine in a stable location.
—
Is the workpiece rmly secured in
place?
Check the mounting condition of the workpiece. If the
workpiece is not mounted on the machine correctly,
the workpiece may come loose during milling and may
become misaligned.
P.24
Is the milling bur worn?
If the same milling bur is used for milling for a long peri-
od of time, it will become worn and aect milling results.
Try replacing the milling bur with a new one. The work
time of the milling bur can also be managed in VPanel.
P.15
Are the milling conditions too
strict?
Strict milling conditions may aect milling results.
Review the CAM milling conditions.
—
Is the adapter properly attached?
Review the mounting condition of the adapter.
If the adapter is not properly attached, it may come
loose during milling and may become misaligned.
P.33
Is the thickness specied in the
CAD data excessively thin?
If the specied thickness is excessively thin, chipping is
likely to occur. Review the shape specied in the CAD
data.
—
To Next Page
