DGSHAPE DWX-52D - Automatic Correction Fails; The Milling Bur Management Information was Lost; The Cleaning Tool Is Not Effective; The Adapter Rattles

Machine Trouble
70
Chapter 4 Troubleshooting
Automatic Correction Fails
Is the automatic correction jig,
detection pin, or ATC magazine
dirty?
Clean away any grime on the automatic correction jig,
the detection pin, and the ATC magazine. These items
being dirty due to a buildup of milling waste or the like
may impede correct sensor operation, making detection
impossible.
P.53
Is the automatic correction jig
properly attached?
Verify that the automatic correction jig is properly
attached.
P.52
P.54
Is the detection pin properly
attached?
Verify that the detection pin is properly attached. Check
the position of the milling bur holder on the detection
pin.
Refer to the "Setup Guide" ("Dimensional Drawings"
(Detection Pin Dimensions)).
P.53
The Milling Bur Management Information Was Lost
Was the machine name (printer
name) changed?
Milling bur info is saved per machine name (printer
name). Before changing the machine name (printer
name), make sure to record the milling bur info sepa-
rately. Milling bur info can be recovered by returning the
machine name (printer name) to the original name.
—
The Cleaning Tool Is Not Effective
Is the cleaning tool effective for the
workpiece being milled?
The cleaning tool is eective for the following workpiec-
es.
Zirconia, composite resin, and CoCr sintered metal
P.38
Is the milling bur holder installed in
the correct position?
The position in which to install the holder to the clean-
ing tool diers from the position in which to install the
milling bur. Install the milling bur holder in the correct
position.
P.38
Have the bristles of the cleaning
tool spread out?
If the cleaning tool bristles spread out, the tool's eec-
tiveness at removing milling waste will be reduced. If the
bristles have spread out, replace the cleaning tool with
a new one.
P.51
Is the detection pin properly
attached?
The cleaning tool uses the length of the detection pin as
a reference. Check the position of the milling bur holder
on the detection pin. Refer to the "Setup Guide" ("Di-
mensional Drawings" (Detection Pin Dimensions)). If the
milling bur holder is not installed in the correct position,
install the milling bur holder in the correct position, and
then perform the automatic correction.
Setup
Guide
The Adapter Rattles
Is the adapter properly attached?
Follow the instructions and attach the adapter again. P.33
