VPanel Window and Functions
13
Chapter 1 Operation Screen
"VPanel" Tab
On this tab, you can set the automatic starting of VPanel and the layout of the top window. When more than one machine is connected,
the machine selected in the top window becomes the target for the setting.
Display Explanation
Layout
Select the layout of the top window.
The selected layout is displayed in the top window.
Initial setting: "Standard"
Standard DWX-52DC compatible
Click "Reset" to return to the "Standard" layout. The screen is displayed in the top window.
Connected machine
selection
Click "Select" to display the screen for selecting the machine to operate.
The machines that can be operated and that are registered on the computer are displayed
in the upper row. The machine that is the target for operation from VPanel is displayed in the
lower row.
Drag the images of the machines in the lower row to the left and right to change the display
order of the machines in the top window.
Run VPanel at PC
start‑up
When this check box is selected, VPanel will start automatically when Windows starts, and the
VPanel icon will be displayed in the task tray.
Initial setting: Selected
To Next Page
