Chapter 2 Milling
Starting Milling
STEP 1: Attaching a Workpiece to the Adapter
The mounting method diers depending on the workpiece type and size.
" P. 24 "For Disk Workpieces"
" P. 27 "For Pin-type Workpieces"
Workpieces can be attached to any adapter.
For Disk Workpieces
Required Items
Adapter Disk workpiece Torque screwdriver
Procedure
Use a torque screwdriver to loosen the adapter screws, turning them approximately 4 times.
(4 locations)
Point
Use the included adapter rack to hold the
adapters.
Use the included spare screws when a screw
is lost or worn.
To Next Page
