Starting Milling
27
Chapter 2 Milling
Use a torque screwdriver to tighten the screws in the positions shown in the gure. (4 locations)
Tighten the screws until they click.
CAUTION
To prevent workpiece damage, tighten the screws in order across the diagonals.
Attach the adapter to the machine.
" P. 33 "STEP 2: Attaching the Adapter to the Machine"
For Pin‑type Workpieces
Required Items
Adapter Pin-type workpiece
Pin-type workpiece
Adapter
Torque screwdriver
1.
Mount the pin‑type workpiece adapter on the adapter.
Use a torque screwdriver to loosen the adapter screws, turning them approximately 4 times. (4 locations)
Use the included spare screws when a screw
is lost or worn.
