Periodic Maintenance
54
Chapter 3 Maintenance
Use the included cloth for care to clean the automatic correction jig and the detection pin.
If any dirt is present in these locations, it may not be possible to perform the correction properly.
Part to be wiped
Automatic correction jig
Also clean the back side and the shaft.
Detection pin
Shaft
Also clean the tip.
Front Back
Load the detection pin in the ATC magazine's number 15 position.
Insert the detection pin rmly.
To Next Page
