Specifications· for Distributor-and-Contact Breaker Unit
l
Direc~ion
, mm
Sparking alternation, deg
Maximum speed at which unint er rupt ed sparking is ens ure d at
standardized three-electrode ne edle discharger, at a length oi
spark gap equal to 7 mm, r.p.m.
Capacitance , ~-tF
f1M05
leit-hand
0.4 to 0.6
180
3000
0.15
to 0.30
Manual adjustment of ignition advance, deg
Mass , kg
18 (minimum)
0.6
Ignition -Coil Specifications
Type E2-E
Rated voltage, V 6
Uninterrupted spark ing is en sured by ignition coil at a speed of
shaft of two - spark distribu~or-and -co ntact breaker unit and at 7 mrn
length of spark gap ~n discharger, r.p.m. .' up to 3000
Each time after repairing breaker f1M302, f1M05 as well as ignition coils
!32-E, !3201, it is necessary to check them for uninterrupt ed sparking on a special 1
bench, in accordance with the specified data .
A
diagram for the ele ctrical equipm ent of motorcycle "Dn epr'' MTIO is pr e-
se nted in Fig. 45.
Repairing the Headlamp
The headlamps should be inspected and repa ired in the case of
<my rep<!irs involving the di s mantling of the motorcycl e.
To correctly perform lhe wiring in the headlamp, take note of
the wire colouring according to the diargam attached to the head-
lamp body.
When inspe c ting the h ead lamp , mak e sure that the terminals arc
reliably connected to the sw itch panel as the loose termimlls will
crea te a high transient resistance and the pilot lamp will glow
weakly with the current-and-voltag e regulator operating c orrectl y.
The
optical element s hould be disassembled only during repla-
ceme nt of the diffuser, taking care to avoid touching th e mirror sur-
face of the reflector.
In
exceptiona l cases the reflector should be washed in a c lean
w arm water by rnaking circular movements with a cotton wool pad
(avo iding pressing the pad to the reflecto·r surface) and periodically
c hanging dirt y water and ·pad. After washing, the refle ctor ha s to be
dried.
at room tet1-Jp e ratur e, in an overturned position (with ' its mir-
ror urface down) .
