INSTALLATION
EPT024619 Issue 1 June 2016 6-9
(3) Slide the 2 Clamps onto the 19 x 300mm Round Bar.
(4) Mount the 19 x 300mm Round Bar with Clamps onto the 19 x 200mm
Round bar.
Clamps
19 x 300mm
Round Bar
