INSTALLATION
6-10 EPT024619 Issue 1 June 2016
(5) Mount the G20i and Anti Shock Clamp onto the 19 x 300mm Round
Bar.
(6) Adjust position of the printer so that it is 3mm further forwards than
the conveyor guide rail.
(7) Tighten all of the screws.
G20i Printer
Product on
Conveyor
Conveyor
Guide Rails
3mm
