- Rotating Atomizer with External Charging
t No.: MRA00001EN
Version:: 07 • As of:: 01/2020
Specific paint data
Painting materials 1K paint (non-flammable)
2K paint (non-flammable)
Painting distance 220 ± 20 mm
Typical paint speed 0.2 – 0.6ms
-1
Viscosity of the paint material 50 – 180 mPas
Paint temperature 20 – 25 °C
Relative humidity 65 ± 5 %
Solid body diameter 5 µm
Material pressure (briefly) maximum 20 bar
Cabin temperature 23 °C ± 3 K
High voltage
Current (I) 400µA max.
Voltage (U) 70 – 80kV
Bell disk
With knurl For primer, single, and clear coat
Without knurl For single and metallic paint
Working material for maintenance
Technical petroleum jelly W32120003
Screw locking Loctite 222 W31010001
Special grease Klüber SYNTHESO
GLEP 1
1000 g
100 g
W32020009
W32020010
