- Rotating Atomizer with External Charging
Version:: 07 • As of:: 01/2020
Fig. 41: Drying the electrode tips and electrode ring
• Dry electrode pins with air.
• Dry electrode ring with air.
7.4.3.4 Bell disk
A T T E N T I O N
Material damage due to unsuitable cleaning agent
The aluminum bell disk is not resistant to water-based cleaning
agents.
Do not immerse the aluminum bell disk in water-based cleaning
agents for extended periods of time.
Fig. 842: Cleaning the bell disk
• Carefully wipe the exterior of the bell disk with a damp cloth.
• Wipe the entire front of the atomizer with a damp cloth.
• Check for damage to the edges of the bell disk.
• Replace damaged bell disk.
• Badly soiled bell disks should be removed and cleaned separately.
Removal and installation of the bell disk are described in the chapter
"Installation of the bell disk."
