Dorr EcoBell2 SL EC - Section 2

Operating Manual
© Dürr Systems AG
EcoBell2 SL EC
- Rotating Atomizer with External Charging
Technical Data
Document No.: MRA00001EN
Version:: 07 • As of:: 01/2020
151 / 156
Position Order number Denomination Number
1 N34960002 O-ring 110x2 1
2 O-ring 98x2 1
3 N34960003 Compression spring 1
4 Piston D8 1
5 O-ring 6x1 2
6 Lid M12x1 1
7 N34960004 Flat seal 12x1 1
8 Needle seal for paint pipe 1
9 Needle seat 1
10 O-ring 8x1 1
11 N34960005 Valve unit L142 main needle 1
12 Valve unit L35 1
13 Ring with carbon fiber brush 1
14 Gland M27x1.5 1
15 N34960006
N34960010
Seal kit storage unit
Seal kit bearing unit (solvent-resistant)
1
1
16 N34960007 O-ring 43x2 1
17 O-ring 34x1.1 1
18 N34960008 O-ring 23.47x2.62 1
19 Complete electrode 6
20 N34960012 O-ring 7x1.5 4
21 Sealing ring D9 2
22 O-ring 4x1.5 5
23 N34960014 Distributor disk D22 (complete) 1
24 N34960016 Lid 1
25 O-ring 10x1 1
26 Pressure pin 1
27 Compression spring 1
28 Cheese-head screw M4 x 25 2
29 3/2-directional control valve 1
30 Plug-in connection 2
31 N34960017 Sealing ring D8 6
32 Mixing tube 1
33 Sealing ring D11 2
