4 Operating principle

Pos: 21 /INP/ Bell2/04_01 Ü bersicht_A A @ 39\mod_1 4085250246 90_20.docx @ 493695 @ 22 @ 1

4.1 Brief description

The EcoBell2 SL is a high rotation atomizer with external charging for

atomizing liquid coating materials with support of electrostatics.

4.2 Overview

Fig. 12: Components of the atomizer

1 Atomizer body 7 Main needle

2 Tube 8 Chuck

3 Screw cap 9 Electrode ring

4 Turbine 10 Light conductor

5 Paint pipe 11 Shaft detent

6 Valve block
