- Rotating Atomizer with External Charging
Version:: 07 • As of:: 01/2020
4.6.1.8 Assembly aid for the atomizer body
Assembling aid for the atomizer body facilitates unscrewing of the
atomizer body.
4.6.1.9 Tool for disassembly of the atomizer body
Pliers facilitate loosening of the atomizer body. The pliers may only be
used for disassembly.
4.6.1.10 External mixer
The external mixer mixes hardener and master lacquer for 2K-paint,
outside the atomizer. The 2K paint is then applied by the atomizer.
4.6.1.11 Cable for potential equalization
The cable for potential equalization connects the flange assembly of
the atomizer to the potential equalization of the system.
4.6.1.12 Tool set
The tool kit contains the tools for maintenance and repairs of the
atomizer.
4.6.2 Related Parts
Material number Denomination
E10110011 EcoHT2 G500 Generator
E03240010 Controller
E03420013 Wiring board
E34010034 R/O converter
4.6.2.1 High tension supply
Generator, controller and wiring boards build the high tension supply
for the atomizer.
If these components are used together with the R/O converter and the
high voltage connection, there is a prototype test for the atomizer. The
atomizer can be operated as a device of the “2G” category.
