- Rotating Atomizer with External Charging
Version:: 07 • As of:: 01/2020
11 Technical Data
Dimensions and weight
Length (without bell disk) 283 mm
Flange diameter 165 mm
Electrodes diameter 244 mm
Weight 6.5kg
Air consumption at 6 bars dynamically
Motor air 100 – 730Nl/min
Motor bearing air approx. 50 Nl/min
Shaping air 1 450Nl/min max.
Shaping air 2 440Nl/min max.
Typical operating range of shaping air 100 – 350Nl/min
Rotational speed
Maximum 70000 ± 500 RPM
Usable range 8000 – 70,000 RPM
Typical range 15,000 – 55,000 RPM
Compressed air, dynamic
Control air valves, min. 6 bar
Control air valves, max. 8 bar
Motor air, min 6 bar
Motor air, max 8 bar
Break air 6 bar
Motor bearing air, min 6 bar
Motor bearing air, max 7 bar
Shaping air, min. 6 bar
Shaping air, max 8 bar
Paint flow rate
Max. outflow rate 700ml/min
At a rotational speed of 70,000 RPM 400 ml/min max.
Typical range 80 – 350ml/min
