Grounding Limit value Measured value
Conveyor / goods carriers <> moving machine <2Ω ●
Moving machine <> control cabinet (e.g. EcoAUC
Bell)
<2Ω ●
Control cabinet <> Central grounding point <2Ω ●
Atomizer (without medium) Limit value Measured value
Paint pipe / nozzle <> Central grounding point
<10Ω ●
Comment: Before checking the speed, the distance between the control air ring and the bell
disk is to be checked.
The distance between the outer edge of the bell disk
and control air ring (1) must be checked with the test
tool W02020284. The information about the surface to
be used for a certain sprayer gun type is engraved on
the testing tool.
Checked:
2 High Voltage EcoHT G500 external charging ATEX category 2G/3G
Insulation measurement with test voltage
1000V
Limit value Measured value
Pickup point work piece <> Central grounding
point
<1MΩ MΩ
Insulation measurement with test voltage 50V Limit value Measured value
Shaft/turbine (with motor bearing air) <> Central
grounding point
<100kΩ kΩ
Set point, actual value comparison
Control display Controller Electrode atomizer
Nominal value Actual value Actual value Actual value
U [kV] I [µA] U [V] I [V] U [kV]
200µA kV µA V V kV
300µA kV µA V V kV
400µA or max. I kV µA V V kV
