Operating principle
Document No.: MRA00001EN
Version:: 07 • As of:: 01/2020
Assembly tool for
assembling the cap
nut
W02020146
Tightening the
cap nut with
auxiliary tool and
torque wrench.
Tightening torque:
8Nm
Centering sleeve for
contact ring
W02020097
Sleeve for
centering the
contact ring on
the flange of the
paint pipe
© 2006 Dürr MAB343BD
