GBK51948 RHINO2
Installation Manual Issue 5
6.5.6 Park Brake Management
6.5.6.1 Park Brake Testing
Parameter Possible Values Default HHP Lite Std Adv
Park Brake Testing
None
Pre-drive
Driving
Pre-drive
✓
This parameter allows you to disable open-circuit testing on the park brake. Disabling
open-circuit testing does not disable short-circuit testing. Short-circuit park brake testing is
ALWAYS performed, even when the parameter is set to None.
Driving — The RHINO2 checks the park brake for open circuit and short circuit faults before
and during driving.
Pre-drive — The RHINO2 checks the park brake for open-circuit before driving, but not
during driving. Use this option when the test during driving is very noisy and/or incorrect
faults are generated. Short circuit faults are still checked pre-drive and during driving.
None — The RHINO2 does not check the park brake for an open-circuit fault. This option
allows the RHINO2 to be used without an electric park brake. Short circuit faults are still
checked.
Warning
For safety reasons, do not use 'None' if the scooter has an electric park brake.
6.5.6.2 Park Brake Neutral Delay
Parameter Possible Values Default HHP Lite Std Adv
Park Brake Neutral Delay 0 - 25500ms 200ms
✓ ✓
The Park Brake Neutral Delay parameter sets the delay between zero speed demand (after
the scooter has decelerated and stopped) and the moment that the park brake is engaged.
Figure 56: Park Brake Neutral Delay
The correct value of this parameter is dependent on the mechanics of the park brake that is
used on the scooter. The delay must be longer for a fast-acting park brake.
Page 106 - Programming
