Dynamic RHINO2 DS90 User Manual

GBK51948 RHINO2
Installation Manual Issue 5
4.1 Electrical Specifications
Parameter Description
Compatible Battery
Supply
24 V supply, 2 x 12 V in series, circuit breaker protected
Compatible Motor 24 V DC permanent magnet type, typically rated 200-1000 watts.
Min Nominal Max Units
Operating Voltage ( V
batt
)
See Note 1
18 24 32 V
Reverse Supply Voltage -32 V
Quiescent Current (idle) 80 mA
Quiescent Current (sleep) 1 mA
Quiescent Current (Key-Off) 1 mA
Charging Current 4 8 A (RMS)
Throttle Resistance (Pin 2 - Pin 8) 4 5 6 kΩ
Speed Limit Pot – Pin 9 (linear) 90 100 110 kΩ
Speed Reduction Wiper – Pin 4, 6 or 12 (log) 9 10 11 kΩ
Current Rating – DS90
l
Continuous (@ 20°C ambient)
36 A
l
Peak (180 seconds @ 20°C initial)
See
warning below
90 A
l
Boost Current
10 A
l
Boosted Current
100 A
l
Boost Time
10 s
Current Rating – DS120
l
Continuous (@ 20°C ambient)
48 A
l
Peak (180 seconds @ 20°C initial)
See
warning below
120 A
l
Boost Current
20 A
l
Boosted Current
140 A
l
Boost Time
10 s
Current Rating – DS160
l
Continuous (@ 20°C ambient)
64 A
l
Peak (180 seconds @ 20°C initial)
See
warning below
160 A
l
Boost Current
20 A
l
Boosted Current
180 A
l
Boost Time
10 s
Current Rating – DS180
l
Continuous (@ 20°C ambient)
64 A
l
Peak (60 seconds @ 20°C initial)
See
warning below
180 A
Page 12 - Specifications
