Dynamic RHINO2 DS90 User Manual

GBK51948 RHINO2
Installation Manual Issue 5
8.1 Neutral Detect Active States
The following options are available to setup a Neutral Detect circuit.
Active
State
Switch
in
Neutral
Switch
connected
to
Neutral Driving
Short
circuit
in
Neutral
Short circuit while driving
Open
wire in
neutral
Open wire while driving
Low Closed
B- (Pin
13)
No
Fault
No
Fault
No
Fault
No Driving, FC7 FC7
Cannot start driving
with an open wire, but a
wire break during
driving is not detected*
High Closed
B+ (Pin
7)
No
Fault
No
Fault
No
Fault
No Driving, FC7 FC7
Cannot start driving
with an open wire, but a
wire break during
driving is not detected*
Open Open
B- (Pin
13)
or
B+ (Pin
7)
No
Fault
No
Fault
FC7
Cannot start driving with
a short circuit, but a
short circuit during
driving is not detected*
No
Fault
FC7
*As soon as the throttle is returned to neutral, the wire fault will result in FC7 and Drive
Inhibit.
