GBK51948 RHINO2
Installation Manual Issue 5
4.2 Physical Specifications
Parameter Description
Aluminium Top, Base and Terminal cover Aluminium alloy ADC12
Protection Rating (with cover) Electronics rated to IP55
Protection Rating (without cover) Electronics rated to IP54
Shipping Weight:
Controller Unit
Terminal cover
DS90, 120, 160, 180
952 grams
55 grams
Min Nominal Max Units
Operating Temperature Range
-25
-13
50
122
°C
°F
Storage Temperature Range
-40
-40
65
150
°C
°F
Operating Humidity Range 0 90 %RH
Connector mating cycles
‡1
l
Battery
30
l
Motor
30
l
Park brake
30
l
Battery charging and programming
30
l
Tiller
30
‡1 Connector descriptions / part numbers can be found in section 5 Installation and testing.
Figure 3: DS90 and DS120 variants Figure 4: DS160 and DS180 variants
For mounting hole dimensions, refer to Section 5.1 Mounting
Page 14 - Specifications
