6.5.3 Drive Performance
The RHINO2 has two Drive Profiles, which are typically used for
l
Drive Profile 1 — Normal Drive
l
Drive Profile 2 - A 'Slow Speed' mode for indoor use that the user can select with a
'Slow' switch. The indoor profile can limit the speed as well as the acceleration.
Normally, Drive Profile 1 is always selected. Drive Profile 2 is only used when Pin [x]
Function is set to 'Profile 2' and the associated input pin is activated.
Note that the following parameters, such as the maximum speed, acceleration and
deceleration rates, can be set specifically to facilitate learner drivers.
6.5.3.1 Maximum Forward Speed
Parameter Possible Values Default HHP Lite Std Adv
Maximum Forward Speed 20 - 100 % See Parameter Variations
✓ ✓ ✓ ✓
Sets the maximum speed in the forward direction when the highest speed has been
selected with the speed limit pot (see 5.9.6 Speed Limit Pot Connections ) and the throttle
is fully deflected forward. Dealers can adjust this parameter to the preference of an
individual user or to the terrain that a specific scooter will be used in.
Note
This parameter cannot be set higher than the value of the Maximum Forward Speed Limit parameter that has
been set by the scooter manufacturer.
6.5.3.2 Forward Acceleration
Parameter Possible Values Default HHP Lite Std Adv
Forward Acceleration 0 - 100 % See Parameter Variations
✓ ✓ ✓ ✓
Sets how quickly the forward speed increases after the throttle has been deflected forward.
0 % — From standstill, the scooter reaches full forward speed in 10 s
100 % — From standstill, the scooter reaches full forward speed in 0.4 s
Figure 49: Acceleration characteristics
GBK51948 RHINO2
Installation Manual Issue 5
Programming - Page 83
