GBK51948 RHINO2
Installation Manual Issue 5
7.5 Advanced Diagnostics Logs
In addition to the standard diagnostics reports, additional diagnostic information is
available from the controller using the Wizard or HHP. This additional information is
extremely useful for identifying the root cause of any faults, and allows for a faster, more
efficient service process. It will also allow for feedback to be given to the user if their use of
the scooter is causing any issues.
There are two sources of the advanced diagnostics logs; the Usage Counters provide
detailed information on the use of the scooter; the Run-time Readings provide real-time
analysis of the system in operation.
7.5.1 Usage Counters (available in both Wizard and HHP)
Counter Description
Powered Up Time The total amount of time (hours) the controller has been turned on.
Powered Up
Count
The number of times the controller has been turned on.
Drive Time
The total amount of time (hours) the controller has been driving (park brake
disengaged).
Drive Count
The number of times the controller has been driving (number of times the park
brake has disengaged).
Deep Discharge
Count
The number of times the batteries have been deep discharged.
7.5.2 Run-time Readings (available in HHP – Technician mode only)
Reading Description
Battery (V) The voltage of the batteries.
Motor (V) The voltage being applied to the motor.
Motor (A) The current being applied to the motor.
Temperature (°C) The internal temperature of the controller.
Temperature (°C) The temperature of the FETs.
Throttle (V) The voltage of the throttle.
Page 130 - Diagnostics
