Dynamic RHINO2 DS90 User Manual

GBK51948 RHINO2
Installation Manual Issue 5
7.2.3 Type 3 Flash Codes
Flash Description
1 Low Battery
2 Bad Motor Connection
3 Motor Short Circuit
4
Current Limit Time-out /
Controller too hot
5 unused
6 Drive Inhibit
7 Throttle Fault
8 Controller Fault
9 Park Brake Fault
10 High Battery Voltage
7.2.4 Type 4 Flash Codes
A Type 4 flash code involves the use of twin flashes to identify the type of fault.
Flash Description
1-1 Thermal Cut-back / Stall
1-2 Throttle Trip
1-3 Speed Limit Pot Fault
1-4 Under Voltage Fault
1-5 Over Voltage Fault
2-1 Main Contactor Driver Off Fault
2-2 Unused
2-3 Main Contactor Fault
2-4 Main Contactor Driver On Fault
3-1
Drive inhibit / OONAPU /
Proc or Wiring Fault
3-2 Brake On Fault
3-3 Pre-charge Fault
3-4 Brake Off Fault
3-5 High Pedal Disable Fault
4-1 Current Sense Fault
4-2 Motor Voltage Fault
4-3 EEPROM Fault
4-4 Power Section Fault
Page 126 - Diagnostics
