8.2 Parts List
Dynamic RHINO2 Installation Manuals
Part Description DCL Part # Qty/Unit
Dynamic RHINO2 Installation Manual GBK51948 1
Dynamic RHINO2 Connectors
Part Description DCL Part # MPN Qty/Unit
Flammability
(UL 94)
DS90 Motor/Park brake Adaptor Loom GLM51981 N/A - V-2
DS120 Motor/Park brake Adaptor Loom GLM51983 N/A - V-2
RHINO2 Battery/Actuator Adaptor Loom GLM51984 N/A - V-2
RHINO2 Motor-4/Ring Terminal Adaptor Loom GLM51985 N/A - V-2
RHINO2 Battery-6/Ring Terminal Adaptor Loom GLM51986 N/A - V-2
RHINO2 Logic Adaptor Loom GLM51987 N/A - V-0
Loom Kit RHINO2 Logic GSM51982 N/A - V-0
Loom Kit RHINO2 4W Motor + 6W Battery GSM51988 N/A - V-0
Loom Kit RHINO2 Ring Terminals GSM51989 N/A - V-0
Crimp Terminal M5 Ring Yellow 10-12AWG GCN1286 0190700123 8 V-0
Crimp Terminal Female Spade 18-22AWG Red
Insulated
GCN1282 0190170014 2 V-0
Tyco 250 Series Lance Connector
Housing 4 Way Plug
GCN0688
GCN51970
172134-1
N/A
1
V-2
V-0
Tyco 250 Series Lance Connector
Housing 6 Way Plug
GCN0689
GCN51971
171898-1
N/A
1
V-2
V-0
Terminal Female 12-14AWG
Tyco 250 Series Lance Connector
GCN0690 170258-2 10 N/A
Crimp Terminal 18-24AWG Molex Mini-fit Jnr GCN0771 39-00-0039 16 N/A
Crimp Terminal 16AWG Molex Mini-fit Jnr GCN0776 39-00-0212 4 N/A
Housing 2 Pin Molex Mini-fit Jnr GCN0884 39-01-3028 1 V-0
Housing 4 Pin Molex Mini-fit Jnr GCN0886 39-01-2045 1 V-0
Housing 14 Pin Molex Mini-fit Jnr GCN0887 39-01-2145 1 V-0
Dynamic RHINO2 Terminal Cover
Part Description DCL Part # Qty/Unit
Terminal Cover (with three screws) GME51934 1
GBK51948 RHINO2
Installation Manual Issue 5
Appendices - Page 143
