Page #131 background image
Code
Fault
source
Sub
code
Meaning
l
Recalibrate throttle
l
Replace the throttle pot
01
Throttle Positive (pin 2 on Tiller Connector) or
Throttle Negative (pin 8 on Tiller Connector) out of spec
l
Check the throttle cables for damage
l
Replace the throttle pot
02
Speedpot fault, treating speedpot as set to minimum
l
Check speedpot cable for damage
l
Replace speedpot
03
Speed Reduction Wiper (SRW) fault, treating as set to minimum
l
Check SRW cable for damage
l
Replace SRW
04
Out Of Neutral At Power Up (OONAPU)
l
Release the throttle and try again
05
Calibration fault
l
Recalibrate throttle
l
Check the throttle cables for damage
l
Replace the throttle pot
06
Throttle calibration in progress
l
Finish the calibration instructions
07
Neutral detect out of neutral
l
Check the throttle cables for damage or loose connections
l
Replace the neutral detect hardware
l
Change the neutral window (see Throttle Neutral Offset and
Throttle Dead-band)
06 I/O 01
Battery gauge fault, battery gauge deactivated
l
Check if the battery gauge cables are damaged or loose
08
09
Internal
fault
All
l
Contact Dynamic
GBK51948 RHINO2
Installation Manual Issue 5
Diagnostics - Page 129
