GBK51948 RHINO2
Installation Manual Issue 5
6.5.2.5 Throttle Response
Parameter Possible Values Default HHP Lite Std Adv
Throttle Response 0 - 100 % 80 %
✓ ✓ ✓
Defines the scooter response to movement of the throttle.
0% — The response to the throttle is linear. If the throttle is held halfway, the scooter will
drive at half its programmed speed.
100% — The response to the throttle is curved. If the throttle is held halfway, the scooter
will drive at around 25% of its programmed speed. This gives the user finer control at low
speed. The curve does not change the maximum speed, so the scooter will still drive at full
maximum speed when the throttle is fully deflected.
Figure 46: Throttle response
6.5.2.6 Throttle Dead-band
Parameter Possible Values Default HHP Lite Std Adv
Throttle Dead-band 0 - 100 % 25 %
✓ ✓
Also commonly referred to as 'Neutral Window', Throttle Dead-band sets how far the
throttle must be moved out of neutral before the controller will begin to drive. The
percentage range is dependent on the value of the Throttle Type parameter.
The speed demand from the throttle remains
at zero while the throttle deflection from
neutral is less than half of the programmed
Throttle Dead-band. As the throttle is
deflected beyond this point and up to the
programmed Dead-band, the throttle
demand increases smoothly from zero so
that there is no abrupt change in demand as
the throttle moves out of neutral. For a
throttle deflection greater than the
programmed Dead-band the speed demand
is proportional to the throttle deflection.
Page 78 - Programming
