6.5.2.7 Throttle Testing
Parameter Possible Values Default HHP Lite Std Adv
Throttle Testing No / Yes Yes
✓
Yes — The RHINO2 tests if the voltage at the throttle wiper has a value that is between
Minimum Throttle Voltage and Maximum Throttle Voltage . This is especially useful when
ISO resistors are used to detect faults in the throttle wiring. If the voltage falls more than
10% outside the limits, a throttle fault is generated, the scooter will not drive and a
'Throttle Fault' flash code is shown on the Status light. For the correct flash code, see the
description of the Flash Code Type parameter.
No — The RHINO2 does not generate throttle faults. This setting is not recommended
because faults in the throttle wiring may not be detected. Use for throttle calibration and
throttle testing only.
For schematics and the use of ISO resistors, see 5.9 Throttle Configuration.
6.5.2.8 Maximum Throttle Voltage
Parameter Possible Values Default HHP Lite Std Adv
Maximum Throttle Voltage 0 - 5 V 4.90 V
✓
Minimum Throttle Voltage 0 - 5 V 0.10 V
✓
Maximum Throttle Voltage sets the maximum expected throttle voltage. Set this parameter
to the voltage that is present at the RHINO2 throttle wiper input (pin 1 of the tiller head
connector) when the wiper of the throttle is moved fully to the Throttle Positive position
(pin 2).
Minimum Throttle Voltage sets the minimum expected throttle voltage. Set this parameter
to the voltage that is present at the RHINO2 throttle wiper input when the wiper of the
throttle is moved fully to the Throttle Negative position (pin 8).
The minimum and maximum throttle voltage parameters determine the operation of the
Throttle Full Scale Deflection and Throttle Dead-band parameters. See the description of
those parameters for details.
If Throttle Testing is set to 'Yes', and the voltage at the throttle wiper input is more than
10% higher than Maximum Throttle Voltage or 10% lower than Minimum Throttle Voltage ,
the controller generates a throttle fault to indicate that an error may have occurred with the
throttle or its wiring.
GBK51948 RHINO2
Installation Manual Issue 5
Programming - Page 79
