GBK51948 RHINO2
Installation Manual Issue 5
Figure 47: Wig-wag setup with Neutral Offset = -0.5 V, Dead-band = 25% and Full Scale Deflection = 80%
6.5.2.9 Throttle OONAPU Testing
Parameter Possible Values Default HHP Lite Std Adv
Throttle OONAPU Testing
None
Non-Latching
Latching
Latching
✓
An Out Of Neutral At Power Up (OONAPU) fault occurs if the throttle is not in the neutral
position when the scooter is switched on. This makes sure that the scooter does not
suddenly start to drive.
If an OONAPU fault exists, the Status LED shows a flash code* and the scooter does not
drive. Return the throttle to the neutral position. The fault goes away and the scooter drives
normally.
Latching — If the throttle is not returned to the neutral position within 5 seconds, the
OONAPU fault becomes a latching fault. To clear the fault, switch the scooter off and then
on again.
Non-Latching — The OONAPU fault never becomes a latching fault. To clear the fault,
simply return the throttle to the neutral position. Use this setting for users who have
difficulty to return the throttle to the neutral position within 5 seconds.
None — An OONAPU fault will never occur. Do not use except for testing purposes or
throttle calibration.
*The flash code that is shown depends on the Flash Code Type parameter.
Note
If an OONAPU fault does not go away after the scooter has been turned off and on, the throttle may be faulty or
incorrectly calibrated. See section 5.9.5 Throttle Calibration for more information.
Warning
If Throttle OONAPU Testing is set to 'None', the scooter is unsafe for normal operation. The scooter can start to
drive unexpectedly if it is turned on while the throttle is stuck or held in a deflected position.
Page 80 - Programming
