GBK51948 RHINO2
Installation Manual Issue 5
Figure 48: Speed scaling
The throttle output is scaled down, not limited, so the throttle does not have a dead-band
when the speed pot is at a low setting.
6.5.2.12 Slam Brake
Parameter Possible Values Default HHP Lite Std Adv
Slam Brake Enable No / Yes No
✓
Slam Brake Threshold 6 - 94% 13%
✓
Slam Brake Enable turns on slam braking in the forward and reverse directions.
Slam braking is applied when the throttle is significantly moved in the opposite direction to
the direction that the scooter is currently moving in (the minimum amount of throttle
movement in the opposite direction is set with Slam Brake Threshold).
During a slam brake, the scooter decelerates with the rate that is set with the Slam Braking
parameter. Be careful when enabling slam braking because this setting may not be suitable
for all scooter types.
6.5.2.13 Enable SRW Open Circuit Testing
Parameter Possible Values Default HHP Lite Std Adv
Enable SRW Open Circuit Testing No / Yes No
✓ ✓ ✓
When Enable SRW Open Circuit Testing is enabled, a fault will be generated when the SRW
resistor is disconnected. This is useful for detecting open circuit faults (e.g. broken wire) in
the SRW circuit.
Page 82 - Programming
