Maintenance – Planned maintenance
10-03-2022 4812331840EN 102
Diesel engine – Oil and filter change
Take great care when draining fluid and oil at high
temperatures. Wear protective gloves and goggles.
It is easier to handle the oil drain plug (1) from under the
engine. Drain the oil when the engine is warm. Place a
receptacle that holds at least 15 litres (4 gal) under the drain
plug.
Change the oil filter. Please read the instruction manual for the
engine.
Dispose of the drained oil and filter separately in the
right manner.
Fuel filter and fuel prefilter replacement
Remove the threaded fuel filter using the filter wrench.
Lubricate the O ring with clean lubricating oil.
Do not prefill the engine fuel filter.
Install the filter on the filter head. Press the filter until the seal
touches the surface of the filter head. Press the fuel filter
another 3/4 of a revolution after contact.
The air needs to be removed from the fuel system after fuel
filter installation.
Check the procedure for removing the air in the engine
manual.
Water Separator Replacement
Remove the threaded water separator using the filter wrench.
Lubricate the O ring with clean lubricating oil.
Do not prefill the engine water separator.
Install the water separator on the filter head. Rotate the water
separator until the seal touches the surface of the filter head.
Rotate the fuel filter another 3/4 of a revolution after contact.
The air needs to be removed from the fuel system after water
separator installation.
Check the procedure for removing the air in the engine manual.
Fig. Left side of engine:
1. Drain plug;
