Technical specifications – General
10-03-2022 4812331840EN 24
Technical specifications – General
engine,
water-cooled
Engine speed, loading/unloading
Engine speed, working/transport
See section “Electrical system” – fuses
2
The tires filled with fluid (up to 495 kg/tire). When
doing tire maintenance, pay attention to their
condition.
Tire Water Blasting procedure
Jack the Roller and turn the tire to bring the valve to the
top position.
Remove the valve core housing and make connection
with tire blasting pump and fill the water with 495 lits per
tire.
Set the final working press (110kpa-16psi) after unjack
the roller in valve position in bottom side.
Tyre blasting must in bead seating with control
pressure & valve position in up position.
