10-03-2022 4812331840EN 72
Securing in closed Container for loading
Securing the CA25-35D/PD Vibratory roller from Dynapac for
transport.
1 – 3= Double lashing, i.e one lashing with two parts secured to two different lashing mounts,
symmetrically located on the right and left sides.
4 – Rubber.
The lashings' permitted distance interval in meters
(1 - 3: Double lashings, LC at least 1.7 tonnes (1700 daN), S
TF
300 kg (300daN))
0,9 - 2,5 0,9 - 2,5 0,1 - 2,5
For lashing 1 is L
1
the distance between the lashing point on the edge of the platform and the
point directly sideways from the lashing point on the roller perpendicular to the platform edge. The
relationship for lashings L
2
and L
3
is the same.
Note - “Shown Pictorial view may not be the same as actual machine view”.
