Operating instructions - Summary
10-03-2022 4812331840EN 73
Operating instructions – Summary
1. Follow the SAFETY INSTRUCTIONS specified in the safety manual;
2. Make sure that all instructions in the MAINTENANCE section are followed;
3. Activate the battery switch;
4. Set the forward/reverse lever in neutral;
5. Set the switch for manual/static vibration to the 0 position;
6. Set rotation starter switch in the position for idle running (950 rpm);
7. Start the engine and allow it to warm up;
8. Set the engine speed control to the operating position (2300 rpm);
9. Set Throttle lever to maximum start position;
10. Move the roller, carefully moving the forward/reverse lever;
11. Test the brakes. Remember that the braking distance will be longer if the roller
is cold;
12. Use vibration only when the roller is in motion;
13. In case of emergency:
− Press the emergency/parking brake button;
− Hold the steering wheel firmly;
− Brace yourself for a sudden stop.
14. When parked
− Press the reserve/parking brake button;
− Stop the engine and chock the drum and wheels.
15. To lift the machine:
− Refer to the relevant section in the Instruction Manual.
16. To tow:
− Refer to the relevant section in the Instruction Manual.
17. When transporting:
− Refer to the relevant section in the Instruction Manual.
18. To recover:
− Refer to the relevant section in the Instruction Manual.
