Machine Description – Instruments/Controls
10-03-2022 4812331840EN 49
Low Fuel
When fuel is low-symbol should come with Orange tell-tale
Parking Brake
When the parking brake applied symbol should come red tell-tale
Parking light
When the parking light applied symbol should come in green
Parking Brake
When the parking brake released and try to start the machine,
symbol should appear to indicate the Parking switch need to
applied in machine starting.
FNR in neutral
When the FNR lever away from neutral and try to start the
machine, Machine, Symbol will appear to indicate the FNR need to
In neutral switch when machine starting.
Work Mode
In working condition work mode need to select before vibration
mode activation, Symbol will appear when work mode switch not
activated.
Driver seat
When the driver away from seat in machine starting and also in
running condition symbol will appear o indicate operator need to
seat.
