CHAPTER 3
Extended Carr
iage
Above Ground Model 250i Mot
orc
ycle Dynamometer Inst
alla
tion Guide
3-22
9
Using the hand wheel, move the carria
ge forward until the holes for the rear
carriage clamps are accessible.
10
Install the two rear carriage clamps and
spacers using two 5/16-18 x 1.5-inch bolts
and two 5/16-inch lock washers,.
Figure 3-
2
4: Install the Rear Carria
ge Clamps
T0
7
8
C
carriage clamp
washer
bolt
spacer
101
103
