ACCESSORIES
Power Carriage
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
3-43
REMOVING THE HAND CRANK
1 Loosen the set screw on the hand crank and remove the hand crank.
2 Using a 7/16-inch wrench, remove the two bolts securing the flange bearing.
Figure 3-47: Remove the Hand Crank
bolt
flange bearing
hand crank
