xLogic SuperRelay User’s Manual
Step 3: Inserting Special Functions (SF)
1. Select the tool if you want to place additional functions
on the programming area.
2. A specific function block is selected using the
symbol bar.
3. The following symbol now appears in the work
area:
Now, move the cursor to the required
position.
The function is inserted by clicking the left mouse
button.
