xLogic SuperRelay User’s Manual
Step 6: Moving
Once the function blocks are inserted and connected, the circuit
program is done. Some follow-up work is needed, however, to
obtain a view of the created circuit that is visible at a glance and
easy to understand. Objects placed in the work area such as
function blocks, lines, and text fields can be moved:
