xLogic SuperRelay User’s Manual
Step 9: Documentation
1. Select function and
click using the right
mouse button.
2. Select the Block
Properties menu
item.
or
Double-click
the function
using the left
mouse button.
3. Another address can be
assigned for each individual input
and output block by means of
block parameter assignment.
However, only the inputs and
outputs not already assigned in the
circuit program are considered in
the selection.
In the case of large or complex programs, it is often useful to divide
up the circuit diagram onto several pages.
To Next Page
