Easy xLogic SuperRelay User Manual

xLogic SuperRelay User’s Manual
160
Electrical isolation Relay
outputs：YES
Transistor :
NO
Relay
outputs：YES
Transistor :
NO
Relay outputs
：YES
Transistor :
NO
Control of a digital
input
YES YES YES
Output voltage Transistor
0~24VDC
Transistor
0~24VDC
Transistor
0~24VDC
Continuous current
Transistor ：
max 0.3A
Relay ：max
10A per relay
Transistor ：
max 0.3A
Relay ：max
10A per relay
Transistor ： max
0.3A
Relay ： max 3A
(Q1-Q4),
max 10A(Q5-Q8)
Incandescent
lamp load
(25000 switching cycles) at
Relay:
1000W(240V)
500W(110V)
Relay:
1000W(240V)
500W(110V)
Relay:
1000W(240V)
500W(110V)
Fluorescent tubes with ballast
(25000 switching cycles)
Relay:
10  58W
(at 240VAC)
Relay:
10
 58W
(at 240VAC)
Relay:
10
 58W
(at 240VAC)
Fluorescent tubes,
conventionally
compensated (25000 switching
cycles)
Relay:
1
 58W
(at 240VAC)
Relay:
10
 58W
(at 240VAC)
Relay:
1
 58W
(at 240VAC)
Short circuit-proof and
overload-proof
YES YES YES
Short-circuit current limitation Approx. 1 A Approx. 1 A Approx. 1 A
Output relay protection B16
Max 16A
B16
Max 16A
B16
Max 8A(Q1-Q4)
Max 16A(Q5-Q8)
Parallel output circuit for
power increase
Not permitted Not permitted Not permitted
Switching rate
Mechanical 10Hz 10Hz 10Hz
Ohmic load/lamp load 2Hz 2Hz 2Hz
Inductive load 0.5 Hz 0.5 Hz 0.5 Hz
Analog
Analog inputs
voltage
0~10VDC 0~10VDC 0~10VDC
Analog input
Number
ELC
-
18DC
-
DA:
8 (DI/AI)
ELC
-
12DC
-
DA:
8 (DI/AI)
ELC
-
E
-
16DC
-
DA:
6DI+2(DI/AI)
