Easy xLogic SuperRelay User Manual

User’s Manual xLogic SuperRelay
159
TYPE
Parameter
ELC-18AC Series ELC-12AC Series ELC-E-16AC
Power
Power voltage 110~240VAC 110~240VAC 110~240VAC
Permissible
range
85…250VAC 85…250VAC 85…250VAC
Permissible
mains
frequency
47…63 Hz
47…63 Hz 47…63 Hz
Power
consumption
．10…30mA
(110VAC)
．10…20mA
(240VAC)
．10…30mA
(110VAC)
．10…20mA
(240VAC)
．10…30mA
(110VAC)
．10…20mA
(240VAC)
Voltage failure
buffering
10ms(110VAC)
20ms(240VAC)
10ms(110VAC)
20ms(240VAC)
10ms(110VAC)
20ms(240VAC)
Power loss 1.1…3.5W(110VAC)
2.4…4.8W(240VAC)
1.1…3.5W(110VAC)
2.4…4.8W(240VAC)
1.1…3.5W(110VAC)
2.4…4.8W(240VAC)
Backup of the
real-time clock
at
25 °C
10 hours 72 hours NO
Real time
accuracy
Max ±5s/day Max ±5s/day NO
Digital inputs
Input number 12 8 8
Electrical
isolation
NO NO NO
Input voltage:
Signal 0
signal 1
< 40VAC
>79VAC
< 40VAC
>79VAC
< 40VAC
>79VAC
Input current
Signal 0
Signal 1
< 0.03mA
>0.08mA
< 0.03mA
>0.08mA
< 0.03mA
>0.08mA
Delay time at
. 0 to 1
. 1 to 0
Type 50ms
Type 50ms
Type 50ms
Type 50ms
Type 50ms
Type 50ms
Line length
(unshielded)
100m
100m 100m
Digital outputs
Output number 6 4 8
