xLogic SuperRelay User’s Manual
160
Output type Relay outputs Relay outputs Relay outputs
Electrical
isolation
YES YES YES
Control of a
digital
input
YES YES YES
Continuous
current
MAX. 10A per relay MAX. 10A per relay MAX. 3A (Q1-Q4)
MAX. 10A(Q5-Q8)
Incandescent
lamp load
(25000
switching
cycles)
1000W(240V)
500W(110V)
1000W(240V)
500W(110V)
1000W(240V)
500W(110V)
Fluorescent
tubes with
ballast (25000
switching
cycles)
10  58W
（at 240VAC）
10  58W
（at 240VAC）
10  58W
（at 240VAC）
Fluorescent
tubes,
conventionally
compensated
(25000
switching
cycles)
1 X 58W
（at 240VAC）
1 X 58W
（at 240VAC）
1 X 58W
（at 240VAC）
Short
circuit-proof
cos 1
Power protection
B16 600A
Power protection
B16 600A
Power protection
B16 600A
Short-circuit
proof cos 0.5 to
0.7
Power protection
B16 900A
Power protection
B16 900A
Power protection
B16 900A
Protection of
output
relay
Max 16A
characteristic B16
Max 16A
characteristic B16
Max 16A
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz 10 Hz
Ohmic
load/lamp load
2 Hz 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz 0.5 Hz
