xLogic SuperRelay User’s Manual
70
Par
Parameter or actual value of another, already configured
function (see "Visible parameters or actual values")
Time: Shows the continuously updated time-of-day
Date: Shows the continuously updated date
EnTime:Shows the time of the 0 to 1 transition
EnDate:Shows the 0 to 1 transition of the date
Output
Q remains set as long as the message text is queued.
Description of the function
With a 0 to 1 transition of the signal at input En, the display outputs your configured
message text (actual value, text, TOD, date) in RUN mode.
Acknowledgement disabled (Ack = Off):
The message text is hidden with a 0 to 1 signal transition at input En.
Acknowledgement enabled (Ack = On):
After input En is reset to 0, the message text is displayed until acknowledged by pressing
the OK button. The message text cannot be acknowledged as long as input En is high.
If several message text functions were triggered with En=1, the message with the highest
priority (1 = lowest, 32=highest) is displayed. This also implies that a new message text is
only displayed if its priority is higher than that of previously enabled message texts.
After a message text is disabled or acknowledged, the function automatically shows the
previously active message text that takes the highest priority.
You can change between the display in RUN mode and the message texts by means of
buttons.
Restrictions
Up to 32 message text functions are available.
Particular characteristics to be noted when configuring
