Un = 110 / 120 Vac / dc
Switching Threshold 3 ON:
Switching Threshold 3 OFF:
Min. 88.0 Vdc / 88.0 Vac
Max. 44.0 Vdc / 44.0 Vac
Un = 230 / 240 Vac / dc
Switching Threshold 4 ON:
Switching Threshold 4 OFF:
Min. 184 Vdc / 184 Vac
Max. 92 Vdc / 92 Vac
Terminals: Screw-type terminal
Relay Outputs
Continuous current: 5 A ac / dc
Max. make current: 25 A ac / dc for 4 s
1000 W (VA) at L/R = 40 ms
30 A / 230 Vac according to ANSI IEEE Std
C37.90-2005
30 A / 250 Vdc according to ANSI IEEE Std
C37.90-2005
Max. breaking current: 5 A ac up to 240 Vac
4 A ac at 230 V and cos φ = 0,4
5 A dc up to 30 V (resistive)
0.3 A dc at 250 V (resistive)
0.1 A dc at 220 V and L/R = 40 ms
Max. switching voltage: 250 Vac / 250 Vdc
Switching capacity: 3000 VA
Operating time: (*) typ. 7 ms
Reset time: (*) typ. 3 ms
Contact type: 1 changeover contact or normally open or
normally closed
Terminals: Screw-type terminals
(*) The operating and reset times are the pure hardware-related switching times (coil –
making/breaking contact), i. e. without the time that it takes the software to calculate the
decisions.
242 www.eaton.com EMR-3MP0
10 Technical Data EMR-3MP0
