Eaton PowerXL DC1 Series - Features

11 Annex
11.1 Features
168 DC1 variable frequency drive 12/13 MN04020003Z-EN www.eaton.com
11.1 Features
Part no.
Rated operational current
Assigned motor output
Radio interference suppression Brake chopper (integrated) Degree of protection Size
I
e
P
(230 V, 50 Hz)
P
(220 - 240 V, 60 Hz)
N = No
F = Yes
N = No
B = Yes
IP FS
[A] [kW] [A]
1)
[HP] [A]
1)
Mains supply voltage: 1 AC 115 V, 50/60 Hz (voltage doubler); EMC: no integrated radio interference suppression filter
Note: The
115-V mains supply voltage is increased to 230 V (output voltage) by an internal voltage doubler.
Motor connection voltage: 3 AC 230 V, 50/60 Hz
DC1-1D2D3…
2.3 0.37 2 1/2 2.2 N N IP20, IP66 FS1
DC1-1D4D3…
4.3 0.75 3.2 1 4.2 N N IP20, IP66 FS1
DC1-1D5D8… 5.8 1.1 4.6 1-1/2
2)
6
2)
N B IP20, IP66 FS2
Mains supply voltage: 1 AC 230 V, 50/60 Hz
Motor connection voltage: 3 AC 230 V, 50/60 Hz
DC1-122D3…
2.3 0.37 2 1/2 2.2 N, F N IP20, IP66 FS1
DC1-124D3… 4.3 0.75 3.2 1 4.2 N, F N IP20, IP66 FS1
DC1-127D0xN… 7 1.5 6.3 2 6.8 N, F N IP20, IP66 FS1
DC1-127D0xB… 7 1.5 6.3 2 6.8 N, F B IP20, IP66 FS2
DC1-12011… 10.5 2.2 8.7 3 9.6 N, F B IP20, IP66 FS2
DC1-12015… 15 4 14.8 5 15.2 N B IP20, IP66 FS3
Mains supply voltage: 3 AC 230 V, 50/60 Hz
Motor connection voltage: 3 AC 230 V, 50/60 Hz
DC1-322D3…
2.3 0.37 2 1/2 2.2 N N IP20, IP66 FS1
DC1-324D3… 4.3 0.75 3.2 1 4.2 N N IP20, IP66 FS1
DC1-327D0xN…
7 1.5 6.3 2 6.8 N N IP20, IP66 FS1
DC1-327D0xB… 7 1.5 6.3 2 6.8 N, F B IP20, IP66 FS2
DC1-32011…
10.5 2.2 8.7 3 9.6 N, F B IP20, IP66 FS2
DC1-32018…
18 4 14.8 5 15.2 N, F B IP20, IP66 FS3
1) The rated motor currents apply to normal internally and surface-cooled three-phase motors with
2) (1500 rpm at 50 Hz, 1800 rpm at 60 Hz).
3) Keep motor specifications in mind (6 A = normalized rated value in accordance with UL 580 C).
4) In certain cases, only operation with a reduced motor load may be possible.
