2018.12.12
© 2017 Eaton. All rights reserved
124
TRSM0940 Service Procedures | Range Synchronizer Disassembly and Assembly
3. Remove the sliding clutch from the pins of the syn-
chronizer ring.
Range Synchronizer Assembly
1. Install the Sliding Clutch on the blocker pins with the
recessed side up.
