Inputs specification Basic & Switch:
Data Value Unit
Floater switch lifting vessel
(potential-free reed contact)
18-19 Terminal
External Enable / enable input
(potential-free contact)
20-21 Terminal
Outputs specification Basic & Switch:
Data Value Unit
Alarm (X1 / 3, 4, 5) / change-over contact 30 (5) V (A)
Empty signal LL 1/2 (X1 / 6, 7, 8) / change-over
contact
30 (5) V (A)
Pump Enable (X1 / 9, 10, 11) / change-over contact 30 (5) V (A)
Lifting vessel (X1 / 12, 13), output 24 V/DC max. 7.2 / min.3.6 W
Additional specification Switch:
Data Value Unit
Valve container 1 (X1 / 14, 15), output 24 V/DC max. 7.2 / min.3.6 W
Valve container 2 (X1 / 16, 17), output 24 V/DC max. 7.2 / min.3.6 W
Technical data
40Rev. 1-06.2018
