9.2 Spare parts list for equipment with article no. 182613 and 182614 (FKM)
Pos. Description Article No. EBS No.
1 Pipe clip with bracket 415018710 10040210
2
Entire cover contains: 282619 10108551
O-ring, 90 x 3 (1 x) 417007580 on request
Throttle screw (1 x) 38851302 10122836
O-ring, 10 x 1.5 (1 x) 417008307 on request
Threaded cable union (1 x) 418441001 10012445
Valve housing (1x) 34000227 10041860
O-ring, 14 x 2.5 (1 x) 417008339 10018165
Elbow threaded connection (1x) 283126 10200899
O-ring, 10 x 2.5 (1 x) 417008327 10016861
Floater (1 x) 282623 on request
O-ring, 8 x 2 (1 x) 417007586 on request
Screw cap (1 x) 38260114 on request
3 Bottom with sighting tube, complete 282622 on request
4 O-ring, 28 x 3.5 (4 x) 417008593 10016464
5 Level switch (1 x) 418264037 10002182
6 O-ring, 14 x 2 (1 x) 417008310 10016283
7 Elbow threaded connection (1x) 283126 10200899
8 Return valve (1 x) 282613 10006255
9 Injector (1 x) 288514 10002456
10 Pipe clip (1 x) 415018704 10122636
11 2/2-Way Solenoid valve (1 x) 417704332 10006162
12 Threaded stud, 3/8"-D8 (1 x) 415101550 10122848
13 * Container straight, D8 (1 x) 415101541 10099262
14 ** Angle joint, D8 (1 x) 415101537 10030870
15 ** Pipe, 6/8 ,PE, blue, 0.91 m 417400355 10039846
16 Pipe, 6/8, PTFE, nature, 0.18 m 417400224 10000312
17 ** Threaded stud, 1/4"- D8 (2 x) 415101549 10030869
18 ** T joint, D8 (2 x) 415101533 10020097
19 ** 3/2-Way Solenoid valve (2 x) 417704123 on request
20 ** Plug with LED display (2 x) 418468025 10001498
21 2/2-way diaphragm valve (2 x) 415502534 10122493
22 ** O-ring, 23 x 2 (4 x) 417007352 10016284
23 ** Valve support (2 x) 415502466 10043772
24 Mounting board control unit (1 x) 32370142 10000420
25
Connexx control unit
contains: 282650 10003861
Housing cover gasket (1 x) 32370123 10016708
Quick fastner with spring (4 x) 418534232 10039835
Connexx board (1 x) 282653 10022290
Microfuse 2A (1 x) 418351081 10012204
Spare parts and accessories
43 Rev. 1-06.2018
